.Buildings.Controls.OBC.ASHRAE.G36.AHUs.MultiZone.VAV.SetPoints.SupplyTemperature

Information

Block that outputs the supply air temperature setpoint and the coil valve control inputs for VAV system with multiple zones, implemented according to Section 5.16.2 of the ASHRAE Guideline G36, May 2020.

The control loop is enabled when the supply air fan u1SupFan is proven on, and disabled and the output set to deadband (no heating, minimum economizer) otherwise.

The supply air temperature setpoint is computed as follows.

Setpoints for TSupCoo_min, TSupCoo_max, TOut_min, TOut_max

Per Section 3.1.4.1, the setpoints are design information.

During occupied and Setup modes (uOpeMod=1, uOpeMod=2)

The TSupSet shall be reset from TSupCoo_min when the outdoor air temperature is TOut_max and above, proportionally up to maximum supply temperature when the outdoor air temperature is TOut_min and below. The maximum supply temperature shall be reset using trim and respond logic between TSupCoo_min and TSupCoo_max. Parameters suggested for the trim and respond logic are shown in the table below. They require adjustment during the commissioning and tuning phase.

Variable Value Definition
DeviceAHU Supply Fan Associated device
SP0iniSetInitial setpoint
SPminTSupCoo_minMinimum setpoint
SPmaxTSupCoo_maxMaximum setpoint
TddelTimDelay timer
TsamplePeriodTime step
InumIgnReqNumber of ignored requests
RuZonTemResReqNumber of requests
SPtrimtriAmoTrim amount
SPresresAmoRespond amount
SPres_maxmaxResMaximum response per time interval

Image of set point reset

During Cool-down modes (uOpeMod=3)

Supply air temperature setpoint TSupSet shall be TSupCoo_min.

During Setback and Warmup modes (uOpeMod=4, uOpeMod=5)

Supply air temperature setpoint TSupSet shall be TSupWarUpSetBac.
