.Buildings.Controls.OBC.ASHRAE.G36.AHUs.SingleZone.VAV.Economizers.Subsequences.Limits

Information

This block implements the single zone VAV AHU minimum outdoor air control with a single common damper for minimum outdoor air and economizer functions based on outdoor airflow setpoint (VOutMinSet_flow) and supply fan speed (uSupFanSpe_actual), designed in line with Section 5.18.6 of ASHRAE Guidline 36, May 2020.

The controller is enabled when the supply fan is proven on (u1SupFan=true), the AHU operation mode uOpeMod is Occupied, and Freeze protection stage uFreProSta is 1 or smaller. Otherwise the damper position limits are set to their corresponding maximum and minimum physical or at commissioning fixed limits, as illustrated below:

Image of damper position limits state machine chart

If limit modulation is enabled, the outdoor air damper position yOutDamPosMin is computed as follows:

  1. Calculate outdoor air damper position yDam_VOutMin_curSpe which ensures minimum outdoor airflow rate VOutMin_flow at current supply fan speed uSupFanSpe_actual as a linear interpolation between the following values set at commissioning:
  2. Calculate outdoor air damper position yDam_VOutDes_curSpe which ensures design outdoor airflow rate VOutDes_flow at current supply fan speed uSupFanSpe_actual, as a linear interpolation between the following values set at commissioning:
  3. Calculate outdoor air damper position yOutDamPosMin which ensures outdoor airflow setpoint VOutMinSet_flow at current supply fan speed uSupFanSpe_actual as a linear interpolation between yDam_VOutMin_curSpe and yDam_VOutDes_curSpe, proportional to ratios of VOutMinSet_flow to VOutDes_flow and VOutMin_flow.
  4. If outdoor airflow setpoint VOutMinSet_flow is zero, yOutDamPosMin should be zero.

The chart below illustrates the OA damper position limit calculation:

Image of damper position limits control chart
