This sequence sets the dampers for snap-acting controlled dual-duct terminal unit with single discharge airflow sensors. The implementation is according to Section 5.11.5.2 of ASHRAE Guideline 36, May 2020. The calculation is done following the steps below.
uCoo > 0
), then the cooling loop output
uCoo
shall reset the discharge airflow setpoint
VDis_flow_Set
from the minimum VActMin_flow
to
cooling maximum setpoint VActCooMax_flow
. The cooling damper shall be
modulated by a control loop to maintain the measured discharge aiflow
VDis_flow
at setpoint. The heating damper shall be closed
yHeaDam=0
.
uCoo=0
and uHea=0
), the
discharge airflow set point VDis_flow_Set
shall be the zone minimum
VActMin_flow
, maintained by the damper that was operative just before
entering deadband. The other damper shall remain closed. In other words, when going
from cooling to deadband, the cooling damper shall maintain the discharge airflow at
the zone minimum set point, and the heating damper shall be closed. When going from
heating to deadband, the heating damper shall maintain the discharge airflow at the
zone minimum set point, and the cooling damper shall be closed.
uHea > 0
), then the heating loop output
uHea
shall reset the discharge airflow setpoint
VDis_flow_Set
from the minimum VActMin_flow
to
heating maximum setpoint VActHeaMax_flow
. The heating damper shall be
modulated by a control loop to maintain the measured discharge aiflow
VDis_flow
at setpoint. The cooling damper shall be closed
yCooDam=0
.
u1HeaAHU=false
), the heating
damper shall be closed (yHeaDam=0
).
u1CooAHU=false
), the cooling
damper shall be closed (yCooDam=0
).
The sequences of controlling dampers position for snap-acting controlled dual-duct terminal unit with single discharge airflow sensors are described in the following figure below.
have_preIndDam
to exclude the option of using pressure independant damper.
