.Buildings.Controls.OBC.RadiantSystems.Heating.HighMassSupplyTemperature_TRoom

Information

Controller for a radiant heating system.

The controller tracks the room temperature set point TRooSet by adjusting the supply water temperature set point TSupSet linearly between TSupSetMin and TSupSetMax based on the output signal y of the proportional controller. The pump is either off or operates at full speed, in which case yPum = 1. The pump control is based on a hysteresis that switches the pump on when the output of the proportional controller y exceeds 0.2, and the pump is commanded off when the output falls below 0.1. See figure below for the control charts.

For systems with high thermal mass, this controller should be left configured as a P-controller, which is the default setting. PI-controller likely saturate due to the slow system response.

Revisions

• August 26, 2021, by Michael Wetter:
  First implementation.
