blockTuningMonitor
Monitor the tuning process
Information
This block detects when a PID tuning period should start and end.
Specifically, the tuning period is triggered to begin when either tOn
or tOff becomes greater than 0.
The tuning period is triggered to end when either tOn
or tOff changes after the tuning period starts, as illustrated below:
Note:
This block monitors the values oftOn and tOff to detect the start and end of the tuning period.
Rapid changes in these values can cause unreliable event triggering during variable time-step integration.
To enhance robustness, a small tolerance eps is introduced.
Increasing eps can help ensure correct event detection if any events are missed.
References
J. Berner (2017). "Automatic Controller Tuning using Relay-based Model Identification." Department of Automatic Control, Lund University.
Parameters
| Type | Name | Default | Description |
|---|---|---|---|
| Modelica.Units.SI.Time | eps | 1E-5 | A small tolerance applied to determine whether a variable is greater than zero |
Connectors
| Type | Name | Default | Description |
|---|---|---|---|
| Buildings.Controls.OBC.CDL.Interfaces.RealInput | tOn | Length for the on period | |
| Buildings.Controls.OBC.CDL.Interfaces.RealInput | tOff | Length for the off period | |
| Buildings.Controls.OBC.CDL.Interfaces.BooleanOutput | triSta | A boolean signal, true if the tuning starts | |
| Buildings.Controls.OBC.CDL.Interfaces.BooleanOutput | triEnd | A boolean signal, true if the tuning completes |
Revisions
-
March 31, 2026, by Michael Wetter:
Corrected unit propagation error that causes Dymola 2026x to not show certain units.
See #2100. -
September 20, 2023, by Sen Huang:
First implementation.
