.IDEAS.Controls.OBC.CDL.Reals.Sources.Pulse

Information

Block that outputs a pulse signal as shown below.

The pulse signal is generated an infinite number of times, and aligned with time=shift.

Revisions

• December 03, 2020, by Milica Grahovac:
  Renamed delay parameter to shift.
  This is for Buildings, issue 2282.
• November 12, 2020, by Michael Wetter:
  Reformulated to remove dependency to Modelica.Units.SI.
  This is for Buildings, issue 2243.
• October 19, 2020, by Michael Wetter:
  Refactored implementation, avoided state events.
  This is for Buildings, issue 2170.
• March 2, 2020, by Michael Wetter:
  Changed icon to display dynamically the output value.
• March 16, 2017, by Jianjun Hu:
  First implementation, based on the implementation of the Modelica Standard Library.
