.Buildings.Controls.OBC.ASHRAE.G36.TerminalUnits.ParallelFanCVF.Subsequences.DamperValves

Information

This sequence sets the fan status, damper and valve position for constant-volume parallel fan-powered terminal unit. The implementation is according to Section 5.7.5 of ASHRAE Guideline 36, May 2020. The calculation is done following the steps below.

  1. When the zone state is cooling (uCoo > 0), then the cooling loop output uCoo shall be mapped to the airflow setpoint from the minimum VActMin_flow to the cooling maximum VActCooMax_flow airflow setpoints. The heating coil is disabled (yVal=0).
  2. When the zone state is deadband (uCoo=0 and uHea=0), then the active airflow setpoint shall be the minimum airflow setpoint VActMin_flow. The heating coil is disabled (yVal=0).
  3. When the zone state is heating (uHea > 0),
  4. The VAV damper shall be modulated by a control loop to maintain the measured airflow at the active setpoint.
  5. Fan control

The sequences of controlling fan, damper position for constant-volume parallel fan-powered terminal unit are described in the following figure below.

Image of damper control for constant-volume parallel fan-powered terminal unit

As specified in Section 5.7.7 of ASHRAE Guideline 36, the airflow setpoint could be override by providing software switches that interlock to a system-level point to:

  1. when oveFloSet equals to 1, force the zone airflow setpoint VPri_flow_Set to zero,
  2. when oveFloSet equals to 2, force the zone airflow setpoint VPri_flow_Set to zone cooling maximum airflow rate VCooMax_flow,
  3. when oveFloSet equals to 3, force the zone airflow setpoint VPri_flow_Set to zone minimum airflow setpoint VMin_flow.

Revisions
