.Buildings.Controls.OBC.CDL.Logical.VariablePulse

Information

Block that outputs a boolean pulse.

The output of this block is a pulse with a constant period and a width as obtained from the input 0 ≤ u ≤ 1, which is the width relative to the period.

The block produces the following ouputs:

• If u = 0, the output y remains false.
• If 0 < u < 1, the output y will be a boolean pulse with the period specified by the parameter period and the width set to u*period.
• If u = 1, the output y remains true.

When the input u changes by more than deltaU and the output has been holding constant for more than minimum holding time minTruFalHol, the output will change to a new pulse with width equal to u*period.

Revisions

• August 11, 2022, by Jianjun Hu:
  First implementation.
