packageHanserModelica
Educational open source library on Modelica, electrical engineering and polyphase electrical machines
Version 2.0.1
Uses Complex 4.0.0, Modelica 4.0.0.
Extends from Modelica.Icons.ExamplesPackage (Icon for packages containing runnable examples).
Information
HanserModelica is a Modelica open source educational library on object oriented modeling applied to electrical engineering and a particular focus on polyphase electric machines. This library is based on a book published in German by Hanser Fachbuchverlag. The User's Guide gives an overview of the contents of the book.
Contents
| Name | Description |
|---|---|
 UsersGuide | User's Guide |
| FirstSteps | First steps |
| VariablesTypes | Variables and types |
| Classes | Modelica classes |
| Electrical | Electrical Modelica concepts |
| Magnetic | Magnetic Modelica concepts |
| Thermal | Thermal systems |
| Rotational | Rotational systems |
| Machines | General models on polyphase electrical machines |
| InductionMachines | Induction machines |
| SynchronousMachines | Synchronous machines |
 MoveTo_Modelica | Package of components currently not supported by OpenModelica 1.13 |
